| Machine Specifications | |
| Voltage | 380v 3ph 50hz |
| Size | 1200x 900 x 1150mm |
| Weight | 530kg |
| Total power | 22kw 30hp |
| Starting method | Y-ΔStarter (Star delta starting) |
| Pipe diameter(inch) | 1'' |
| Motor shell material | Aluminum |
| Free air deliver/Discharge pressure (m3/min/Mpa) | 3.8/0.8/3.6/1.0 |
| Free air deliver/Discharge pressure (CFM/PSI) | 134/116/127/145 |
| Drive method | Direct driven |
| No.of compression stage | Single stage |
| Cooling mode | Air cooling |
| Ambient temperature(0C) | -5--+45 |
| Discharge temperature(0C) | Ambient temperature +15 |
| Lubricant(L) | 14.5 |
| Noise level(Db) | 65±2 |
